Annoy#

Examples for annoy cover approximate nearest-neighbor index construction, querying, persistence, memory mapping, precision trade-offs, and lower-level native/Cython interfaces.

The gallery intentionally contains several API layers. Most users should start with the public Python Index interface and move to the lower layers only when they need dtype/native compatibility or implementation-level benchmarking.

See also

Start here: ANNoy Vector Index DB#

1. Simple nearest-neighbor search

Start with plot_simple_script.py.

It demonstrates the shortest useful workflow:

from scikitplot.annoy import Index

index = Index(
    f=3,
    metric="angular",
)

index.add_item(0, [1, 0, 0])
index.add_item(1, [0, 1, 0])
index.add_item(2, [0, 0, 1])

index.build(-1)

print(index.get_nns_by_item(0, 10))
print(index.get_nns_by_vector([1.0, 0.5, 0.5], 10))

Use this page to understand the core lifecycle before looking at persistence, Cython, legacy, or benchmark examples.

Choose the right API layer#

The gallery contains three distinct layers.

Layer

Typical import

Use when

Public Python API

from scikitplot.annoy import Index

normal application code and new examples

Cython/native API

from scikitplot.annoy._annoy import Index

dtype/native experiments, implementation-level testing

Legacy C-extension API

scikitplot.cexternals._annoy

compatibility testing and migration work

Prefer the public Python API unless the example is specifically teaching a lower-level contract.

Private/internal imports in the advanced examples are deliberate teaching or maintenance surfaces; they should not be copied into ordinary application code without understanding their compatibility implications.

Core index lifecycle#

The common Annoy lifecycle is:

vectors
   ↓
Index(f, metric)
   ↓
add_item(...)
   ↓
build(n_trees)
   ↓
query
  ├── get_nns_by_item(...)
  └── get_nns_by_vector(...)
   ↓
optional save(...)
   ↓
optional load(...) / mmap-backed querying

Build parameters affect index construction, while query parameters affect the search work performed against an already-built index.

Metrics#

Examples use several supported metric families, including:

angular

cosine-like angular distance for directional similarity.

euclidean

L2 distance.

manhattan

L1 distance.

dot

dot-product-oriented similarity.

hamming

Hamming-distance-oriented indexing where supported by the selected native type combination.

Not every dtype/metric/native combination should be assumed equivalent. Use the public API defaults for ordinary applications and the Cython examples when explicitly investigating concrete type combinations.

Persistence and memory mapping#

plot_mmap_script.py demonstrates the persistent workflow:

index.save("example.annoy")

restored = Index(
    f=3,
    metric="angular",
)
restored.load("example.annoy")

Annoy indexes are designed to support file-backed querying. Keep the vector dimension and metric consistent with the index that was written.

Treat bundled .annoy / .tree files in this gallery as example/test artifacts, not as a stable cross-version interchange format unless the relevant compatibility contract has been explicitly verified.

Precision and benchmark examples#

The precision and benchmark pages are not beginner tutorials.

They may:

  • generate many random vectors,

  • build many trees,

  • exercise multiple dtype/metric combinations,

  • launch subprocesses or pytest benchmarks,

  • write index artifacts,

  • consume substantially more CPU, memory, or disk than the simple example.

Use them for engineering comparison, regression testing, or capacity planning. Do not infer production sizing from a single gallery benchmark.

Hamlet Cython showcase#

plot_annoy_cython_hamlet_example.py is the broadest Annoy demonstration.

It uses a real text corpus, converts passages to vectors, and compares native Annoy behavior across advanced configurations.

Conceptually:

Hamlet passages
    ↓
text vectorization
    ↓
native Annoy Index
    ↓
dtype / metric variants
    ↓
nearest-neighbor search
    ↓
build-time / size / retrieval comparison

Use it after the public Python examples. It is a showcase of the lower-level native implementation surface, not the minimum API required to use Annoy.

Native capability#

Annoy in scikit-plots includes compiled/native components. A gallery or CI environment may therefore have the Python package available while a required native implementation is unavailable for that platform/build.

The desired gallery rule is:

native Annoy capability unavailable

Report a specific SKIP when the example cannot truthfully continue.

native Annoy imports successfully but build/query fails

Fail visibly. Do not convert an installed-backend regression into a skip.

The same distinction applies to compiler-dependent benchmark examples.

Files and working directories#

Several historical/advanced examples read or write artifacts such as:

*.annoy
*.tree
*.npy
*.csv
*.joblib

New examples should prefer a temporary directory or a path derived from the example location rather than relying on the caller’s current working directory.

Gallery examples should not overwrite repository test fixtures merely to demonstrate persistence.

Reproducibility#

For deterministic examples:

  • seed random-number generators where random vectors are generated,

  • keep dimensions and item counts bounded,

  • print bounded result summaries,

  • separate correctness checks from performance measurements,

  • record the metric, number of trees, and query parameters used for benchmark comparisons.

Approximate nearest-neighbor results can depend on build/search configuration; benchmark pages should make those parameters visible.

Relationship to Corpus and MCP#

Annoy can also be used as a retrieval backend by higher-level scikit-plots components.

For document retrieval:

scikitplot.corpus
    ↓
document embeddings
    ↓
Annoy vector backend
    ↓
retrieval

For a protocol/server workflow:

Corpus
  ↓
Annoy
  ↓
CorpusAnnoyRetriever
  ↓
scikitplot.mcp

Use the Corpus/MCP galleries when the goal is document ingestion or MCP serving. Use this Annoy gallery when the goal is understanding and validating the vector index itself.

CI guidance#

A practical CI split is:

Portable/public API gate

Run the small public Python examples and focused Annoy tests.

Native capability gate

Run Cython/native examples only on environments that intentionally provide the required compiled extension.

Benchmark gate

Keep expensive dtype/precision/compiler benchmarks separate from the normal documentation build when they materially increase build time or resource consumption.

An unavailable optional native/compiler capability should be reported explicitly. Security, serialization, index-corruption, or installed-backend failures should remain visible.

Browser / WASM note#

Do not assume that the native Annoy implementation, memory mapping, filesystem semantics, subprocesses, or C/C++ compiler examples are available in JupyterLite/Pyodide/other browser-WASM runtimes.

Use the simple/public API examples there only when the relevant native package has been explicitly built and verified for that runtime.

The Cython, mmap, compiler, and benchmark pages should otherwise be treated as reference material in browser environments.
