Mcp#

Examples for mcp focus on exposing local scikit-plots evidence through a small, read-only Model Context Protocol (MCP) surface.

The current showcase connects three public submodules:

scikitplot.corpus: builds deterministic local evidence with HAMLET_TEXT and HashEmbedder.
scikitplot.annoy: provides the optional native approximate-nearest-neighbor backend.
scikitplot.mcp: serves the indexed evidence through search_docs and docs://chunk/{doc_id}.

# MCP server/client dependencies
pip install scikit-plots[mcp]

# Verify the centralized CLI
scikitplot mcp --help

Start here#

Serve a real Hamlet corpus over MCP with Annoy

The showcase follows one complete local workflow:

HAMLET_TEXT
    ↓
local corpus directory
    ↓
HashEmbedder
    ↓
Annoy
    ↓
CorpusAnnoyRetriever
    ↓
scikitplot mcp --self-test
    ↓
scikitplot mcp --docker
    ↓
MCP client context
    ↓
search_docs(...)
    ↓
citations + docs://chunk/{doc_id}

It is intentionally built from local data so the retrieval result does not depend on a model download or an external document service.

Execution layers#

The example separates increasingly optional capabilities instead of requiring the full server stack for every documentation build.

Layer	Requires	Normal purpose	If unavailable
Hamlet corpus	Corpus core	create local evidence	runs normally
Hash embedding	NumPy / Corpus core	deterministic document/query vectors	runs normally
Corpus + Annoy retrieval	native `scikitplot.annoy`	real ANN search	specific `SKIP`
CLI `--self-test`	Corpus + Annoy	verify backend without opening a server	specific `SKIP` when Annoy is absent
MCP HTTP server	MCP server dependencies	expose tools/resources	specific `SKIP`
MCP client round trip	MCP SDK + local server	verify the real protocol boundary	run only in provisioned CI/manual environments

CLI self-test first#

Before opening a listening server, validate the exact Corpus + Annoy configuration with the bounded CLI self-test:

scikitplot mcp \
    --corpus-annoy /tmp/scikitplot-mcp-hamlet \
    --hash-dimension 256 \
    --annoy-n-trees 10 \
    --self-test \
    --self-test-query "sleep dream death" \
    --self-test-require-match

This is the preferred first CI gate because it verifies corpus loading, embedding, index construction, querying, and the MCP result contract without requiring an HTTP client/server round trip.

Two-terminal server workflow#

Terminal 1 — server

scikitplot mcp --docker \
    --host 127.0.0.1 \
    --corpus-annoy /tmp/scikitplot-mcp-hamlet \
    --hash-dimension 256 \
    --annoy-n-trees 10

Terminal 2 — client

from mcp import Client

async with Client("http://127.0.0.1:8000/mcp") as client:
    result = await client.call_tool(
        "search_docs",
        {
            "query": "sleep dream death",
            "k": 3,
        },
    )

print(result.structured_content)

The showcase also polls /healthz before creating the client and always terminates the server subprocess during cleanup.

CI / documentation mode#

For an ordinary documentation build, keep the live HTTP round trip disabled:

export SCIKITPLOT_GALLERY_RUN_MCP_DOCKER=0

To execute the full local server/client round trip in a provisioned CI container:

export SCIKITPLOT_GALLERY_RUN_MCP_DOCKER=1
python galleries/examples/mcp/plot_mcp_corpus_annoy_hamlet_script.py

The CI subprocess explicitly binds to 127.0.0.1. This keeps the unauthenticated showcase server on loopback rather than exposing it beyond the container/host merely to test the protocol path.

What `--docker` means here#

The example invokes:

scikitplot mcp --docker ...

through Python’s subprocess module.

It is the scikit-plots MCP server’s Docker-oriented runtime profile; the Python gallery itself is not a replacement for docker run or container orchestration. The same command can be launched inside your normal CI/Docker environment.

Gallery reliability rule#

The MCP examples use the same reliability distinction as the Corpus gallery:

missing optional native Annoy / MCP SDK / intentionally disabled live server: Report a visible, specific SKIP when the remaining example can stay truthful.
invalid public API / broken installed backend / malformed MCP result / server crash: Fail visibly. Do not convert a real integration regression into a skip.

The local deterministic path must never fabricate Annoy or MCP success when those capabilities were not actually exercised.

Security and lifecycle#

The showcase is read-only and uses bounded result previews.

For automated server execution it also:

chooses a free loopback port,
waits for /healthz before connecting,
binds explicitly to 127.0.0.1,
terminates the child process in a finally/context cleanup path,
escalates to kill() only if graceful termination exceeds the timeout.

Treat wider network exposure, authentication, reverse proxies, TLS, and production process supervision as deployment concerns rather than gallery defaults.

Browser / WASM note#

The deterministic Corpus and hashing pieces are portable Python/NumPy candidates. Native Annoy, subprocess management, listening sockets, and a real MCP HTTP server should not be assumed available in JupyterLite or other browser/WASM runtimes.

Use the gallery there as architecture/reference material unless those runtime capabilities have been explicitly verified.

Serve a Real Hamlet Corpus over MCP with Annoy
